USER’S MANUAL 8-1
8: ADVANCED INSTRUCTIONS
Introduction
This chapter describes the advanced instruction menus, terms, available operands, formats, and data types used for
advanced instructions.
Advanced Instruction Menus
Advanced instructions are programmed using the ADV key of the program loader. To program an advanced instruction
using the program loader, select the address where you want to program an advanced instruction, and press the ADV and
keys to display the first menu of advanced instructions:
[MENU1]
0:NOP 3:+-*/
1:MOV 4:LOGIC
2:CMP 5:SFT
ADV
[MENU2]
7:CLK A:HSC
8:I/F B:COMM
9:EXT
0 NOP
1 END
2 END
3 END
[MOV MENU]
1:MOV 4:IMOVN
2:MOVN
3:IMOV
[CMP MENU]
1:= 4:>
2:<> 5:<=
3:< 6:>=
[+-*/ MENU]
1:ADD+ 4:DIV/
2:SUB-
3:MUL*
[LOGIC MENU]
1:ANDW
2:ORW
3:XORW
[BIT SFT MENU]
1:SFTL 4:ROTR
2:SFTR
3:ROTL
[CLOCK MENU]
1:CALR 4:CLKW
2:CALW 5:ADJ
3:CLKR
[I/F MENU]
1:DISP 4:ANR1
2:DGRD
3:ANR0
[COMM MENU]
1:TXD
2:RXD
3:CMP2
The MENU1 of advanced instructions include
six headings of submenus. To show a sub-
menu, press a number 0 through 5. When the
submenu is displayed, press a number to pro-
gram a required advanced instruction, then the
program screen is displayed to enter operands.
The NOP instruction is entered at the selected
address in the editor screen immediately when
0 is pressed while the MENU1 is displayed.
It is also possible to jump from the editor
screen to the submenu by pressing the ADV
key and a number, 0 through 9, A or B.
The MENU2 includes five submenu headings.
As described above, to go to a submenu, press
a number key 7 through B. When the submenu
is displayed, press a number to program a
required advanced instruction, then the pro-
gram screen is displayed to enter operands
To go back to MENU1 from MENU2, press
the key.
Details of programming advanced instructions
are described in the following chapters.
Press the 0 key. Press the 3 key.
Press the 1 key.
Press the 2 key.
Press the 7 key.
Press the 8 key.
Press the 4 key.
Press the 5 key.
Press the B key.
To show the MENU2 of advanced instructions,
press the key while the MENU1 is dis-
played.
[EXT MENU]
1:PULS
2:PWM
3:A/D
Press the 9 key.
[HSC MENU]
1:HSC0 4:HSC3
2:HSC1
3:HSC2
Press the A key.
