USER’S MANUAL A-1
APPENDIX
Execution Times for Instructions
Instruction Operand and Condition
Maximum Execution Time (µsec)
Standard Processing High-speed Processing
LOD, LODN
I, Q, M 2.0 0.4
R, T, C 2.0 0.8
OUT, OUTN
4.0 1.0
SET, RST
Q, M 3.4 0.8
R 3.4 1.2
AND, ANDN, OR, ORN
I, Q, M 1.4 0.2
R, T, C 1.4 0.6
AND LOD, OR LOD
1.2 0.4
BPS
7.0 5.0
BRD
1.4 0.6
BPP
6.0 6.0
TIM, TMH, TMS
When stopped 23 44
While timing down 31 52
After timeout 31 51
CNT
0
Preset input ON 20 41
After countout 20 40
Others 18 39
1
Pulse input ON 16 37
After countout 19 40
Others 14 35
2 to 31
(2 to 15)
Reset input ON 12 32
After countout 22 43
Others 21 42
CC=, CC≥
12 32
SFR, SFRN
(N bits)
Reset input ON 0.4N + 27 0.4N + 48
Pulse input ON 0.4N + 32 0.4N + 54
Others 28 48
SOTU, SOTD
17 37
JMP, JEND, MCS, MCR
6.0 5.0
END
See the next page.
MOV, MOVN
M → M 109 129
D → D6180
CMP=, <>, <, >, <=, >=
M ↔ M → M 121 140
D ↔ D → M80 99
ADD
M + M → D 121 141
D + D → D8099
SUB
M – M → D 121 141
D – D → D8099
MUL
M × M → D 131 151
D × D → D 90 109
DIV
M ÷ M → D 182 201
D ÷ D → D 140 159
