Error Messages for Program Loader Operation
When using the program loader for programming or transferring a user program, the following error messages may be displayed.
Error Message Error Details
Calendar NG Invalid calendar data.
CRC Code NG The CRC code of the user program to be transferred is incorrect.
Data Clear NG The designated data cannot be initialized.
Double Out Error The same output operand is used repeatedly.
Expansion Unit Program loader is connected to the
MICRO
3
base unit at the expansion station.
No Connect Memory card is not inserted.
Operand NG Invalid operand.
Pass Word NG Incorrect password.
PC Run Error The
MICRO
3
base unit is in the run state, and user program cannot be transferred.
Prg. NG–(A )
User programs are different between the program loader and the
MICRO
3
base unit.
Address is displayed in 4 digits.
Prg. NG–(FUN )
FUN settings are different between the program loader and the
MICRO
3
base unit.
FUN number is displayed in 2 digits.
Prg. Size NG Invalid user program size selection (FUN11).
Program Over User program exceeds the program size selected with FUN11.
Protected Card The write protect switch on the memory card is set to protect.
Protected PC The
MICRO
3
base unit is read and/or write protected.
Receive Error Line disconnection.
Receive Error 0 Invalid BCC code of the received data.
Receive Error 1 Data parity, framing, or overrun error.
Receive Error 2 Time over between data characters.
Receive Error 3 Invalid communication command.
Receive Error 4 Invalid communication procedure (protocol).
System Card ???? A system card is inserted. The ID number is displayed in 4 digits.
T/C Data NG Invalid timer/counter data.
Unformat Card The memory card is not formatted to store user programs.
Unrecognized One Incompatible memory card.
Data Over Transmit/receive data designation exceeds 200 bytes (
MICRO
3
C only).
Setting NG
The protocol selector switch is not set to 3 when using FUN50 user communication data
monitor (
MICRO
3
C only).
Speed Mode Error TXD/RXD is programmed in the high-speed mode (
MICRO
3
C only).
