IDEC MICRO3 User Manual

1: GENERAL INFORMATION
1-14 USER’S MANUAL
Digital DC Output (Transistor Sink Output) Specifications
I/O Type 10-I/O Type 16-I/O Type 24-I/O Type
Output Protection Without protection
Protection Circuits Prepared by User See page 1-23.
Output Points 4 points 7 points 10 points
Output Points per Common Line
COM0 4 points 4 points 5 points
COM1 — 3 points 5 points
Rated Load Voltage 24V DC
Operating Load Voltage Range 19 to 30V DC
Rated Load Current 0.5A per output point
Maximum Load Current 0.625A per output point (at 30V DC)
Voltage Drop (ON Voltage)
1.5V maximum (voltage between COM and output termi-
nals when output is on)
Inrush Current 5A maximum
Leakage Current 0.1 mA maximum
Clamping Voltage 39V±1V
Maximum Clamping Load 10W
Inductive Load
Continuous operation of T
0.95 = 60 msec (DC13) at 1 Hz,
24V DC
External Current Draw
10 mA maximum, 24V DC (power supply to the +V termi-
nal)
Maximum Frequency Response
Test Condition:
Load resistance 1 kΩ, 24V DC
Q0 10 kHz minimum
Q1-Q31 1 kHz minimum (not including scan time)
Isolation
Between Output Terminal and FG 1,500V AC
Between Output Terminal and
Internal Circuit
Photocoupler isolated
Between Output Terminals of
Different COM Lines
Not isolated
Effect of Improper Connection
When a current larger than the rated current flows, perma-
nent damage of output elements may be caused.
Output Status by
MPU Operation
Stop OFF
Power Interruption over 25 msec OFF
Power Interruption 25 msec or less ON/OFF status maintained
Power Up OFF until MPU starts to run
Others (IEC 1131-2 Information)
IEC 1131-2 3.3.3.3 3) Not applicable
IEC 1131-2 3.3.3.3 8) Not applicable
IEC 1131-2 3.3.3.3 9) Not tested for other categories
IEC 1131-2 3.3.3.3 10) Not multichannel module
IEC 1131-2 3.3.3.3 16) Output can not be replaced
because of non-modular structure
IEC 1131-2 3.3.3.3 18) Non-latching type output operation
IEC 1131-2 3.3.3.3 19) Not multi-circuit module
