ifm Vision Assistant O3M
48
The result settings affect the connection of the device within the application.
The connection settings between ifm Vision Assistant and the device are described in chapter
„4.1.2 Manual connection“.
Button Name Description
Using the results
Use the "CAN" setting if the measurement results of the
application are transferred via CAN.
Use the "Ethernet" setting if the measurement results of the
application are transferred via Ethernet.
Use the "CAN & Ethernet" setting if the measurement results
of the application are transferred via CAN and Ethernet.
Repetition rate
The setting determines the repetition rate of the data. A high
repetition rate increases the data flow-rate.
The repetition rate of the data depends on the ambient
temperature
(→ Seite 43, image settings - environment).
The setting affects the: Data refresh to CAN / Ethernet in
relation to the sensor cycle (→ „7.2 CAN settings“) / (→ „7.3
Ethernet“).
► Click on [Next].
