14 Installation and assembly
BIESSE S.p.A. © - p726k0003.fm251111
113
14.7.1 Connection cable
The table pertaining to your machine can be consulted in the main switch in the electrical diagram.
14.7.2 Power levels of the Primus 184/322/324
For the data regarding the intensifier, refer to the manufacturer's manual.
Power conductors for electrical connection in mm²
Switch rating Minimum section Maximum section Cable type Tightening torque
30A 10mm² 50mm² Cu 7 Nm
40A 16mm² 50mm² Cu 7 Nm
63A 25mm² 50mm² Cu 7 Nm
80A 35mm² 50mm² Cu 7 Nm
Power conductors for electrical connection in AWG
Switch rating Minimum section Maximum section Cable type Tightening torque
30A AWG 8 AWG 2 Cu *45lb-in (5.4Nm)
*
Terminal lug not required
40A AWG 6 AWG 1/0 Cu *120lb-in (5.4Nm)
63A AWG 4 AWG 1/0 Cu *120lb-in (5.4Nm)
80A AWG 2 AWG 1/0 Cu *120lb-in (5.4Nm)
Rating
*Installed power (kW)
*
To consult the table pertaining to your machine, compare the power values with the values
shown in the electrical diagram.
For the correct connections, refer to the data indicated in the electrical diagram.
Rated voltage (V) Rated current (A)
12/15/21 200-220-230 44/55/74
12/15/21 380-400-415 22/28/39
12/15/21 440-460-480 19/25/34
