Intermac Primus 184 - 2.2 Configurations of the Primus line

2 Machine description
22
BIESSE S.p.A. © - p702k0003.fm251111
2.2 Configurations of the Primus line
The Primus line of machines (* ) includes the following models:
 Primus 184
 Primus 322
 Primus 324
The first two numbers identify the size of the work table in relation to the X-axis;
the last number identifies the length of the table in relation to the Y-axis.
This manual has been drawn up for the entire Primus line, so the operator is advised
to refer to the relevant paragraphs for the specific model purchased.
Each model is identified by the corresponding plate fixed to the machine, in the point indicated in
paragraph 2.10 “Identification of the manufacturer and the machine”.
Primus 184
Depending on the optional extras requested, the machine is configured as follows:
 Machine with a standard 3-axis head (X, Y, Z)
 machine with a 5-axis head (X, Y, Z, A, C)
Primus 322
Depending on the optional extras requested, the machine is configured as follows:
 machine with one or two heads of 3 or 5 axes each
 pendular mode option
Primus 324
Depending on the optional extras requested, the machine is configured as follows:
 machine with one or two heads of 3 or 5 axes each
 pendular mode option
*
For further information about the dimensions of the various machine models, refer to chapter 7.
