Replace the oil separator filter
The job of the oil separator filter (assembled upstream from the pressure regulator) is to eliminate
the oil from the compressed air before the latter is injected into the machine's system.
To replace the oil separator filter, carry out the following operation every 3000 hours:
1. Grip the cup A and push it slightly upwards before turning it clockwise and pulling it
downwards to remove it.
2. Turn the filtering element B clockwise to remove it.
3. To reassemble, follow the above steps in the reverse order.
Consult the spare parts manual or contact customer support for the spare part code.
The filter is equipped with automatic discharge.
When disposing of the parts, respect the local and national regulations in force.
B
A
