Intermac Primus 184 - Topping up the level of lubricant in the pump

11 Routine and special maintenance
BIESSE S.p.A. © - p714k0003.fm251111
75
Topping up the level of lubricant in the pump
The lubricant is contained in the special tank, and is pushed through the tubes of the pneumatic
pump until it reaches the mechanical parts concerned. To top up the lubricant in the centralised
lubrication system, proceed as described below (after disconnecting the pneumatic system).
 Fill the manual pump with AGIP GR MU EP 0 lubricant.
 Connect the pump to the greasing nipple A and insert the lubricant to the maximum level (i.e.
until the lubricant seeps out of the drainage hole B).
A
B
