Intermac Primus 184 - 12.2 General data; 12.3 General intensifier data

12 Technical characteristics
92
BIESSE S.p.A. © - p724k0003.fm251111
12.2 General data
General data
* machine in pendular mode version
**excluding the working dimensions of the abrasive delivery tubes
General data
12.3 General intensifier data
For further details, refer to the Intensifier Manual.
184
Length (mm): 6490
Width (mm): 3900
Maximum height (mm): 2470
Pneumatic system air consumption (Nl/min): 500
Air pressure (bar) 7
322 322*
Length (mm): 4510 4510
Width (mm): 6280 6730
Maximum height (mm): 2470** 4700
Pneumatic system air consumption (Nl/min): 100 100
Air pressure (bar) 7 7
324
Length (mm): 6710
Width (mm): 6280
Maximum height (mm): 3000
Pneumatic system air consumption (Nl/min): 100
Air pressure (bar) 7
Power 22 kW 37 45 kW 75 kW
Max. operating pressure 420 Mpa 420 Mpa 420 Mpa 420 Mpa
Max. water consumption 3.8 l/min 3.8 l/min 4.1 l/min 7.8 l/min
