12 Technical characteristics

BIESSE S.p.A. © - p724k0003.fm251111

12.1 Layout

Primus 184

1510

1410

2470

900 970

1900

3900

7402420740

6490

810 5680

1290

1150

point of connection to the electric system; (height from the ground = 930mm)

point of connection to the pneumatic system; (height from the ground = 740mm)

point of connection to the water system; (height from the ground = 450mm)

cabinet with PC
