Intermac Primus 184 - 12.8 Main machine axes - X, Y, Z

12 Technical characteristics
94
BIESSE S.p.A. © - p724k0003.fm251111
12.8 Main machine axes - X, Y, Z
Axis stroke of Primus 184
Axis stroke of Primus 322
Axis stroke of Primus 324
The axis movement operations may cause collisions, so they should be carried out
with the greatest CARE on the part of the operator.
Machine axis X Y Z
Primus 184 - linear speeds (m/min) 54 38,5 9
Primus 322 - linear speeds (m/min) 45 45 15
Primus 324 - linear speeds (m/min) 45 45 15
Machine axis 3 axes 5 axes
X 1860mm 1700mm
Y 4000mm 3800mm
Z 250mm 200mm
A - +60° / -60°
C - infinite
Machine axis 3 axes 5 axes
X 3210mm mm
Y 2000mm mm
Z 250mm 200mm
A - +60° / -60°
C - infinite
Machine axis 3 axes 5 axes
X 3210mm mm
Y 4000mm mm
Z 250mm 200mm
A - +60° / -60°
C - infinite
