Invacare®LiNX
Outputs
Supportedoutputsare:
•Seating
•Drive
•ControlOutputs(Outputmodule)
•Functions
•Navigation
•Lighting
•Horn
•Connectivity
Seating:SelectSeatingtosettheoutputtocontrolthepositionoftheseat,backrestandlegs.Thisoutputcanbe
toggled,switchedandlatched.
Output
Choice1Choice2
Seating
TiltToggle
ReclineToggleLatch
ElevateSwitchedExtend
LeftLegSwitchedRetract
RightLegLatchedExtend
BothLegsLatchedRetract
ReclineandLegs
LNX
Drive:SelectDrivetosettheoutputtocontrolthewheelchairspeedandtogglebetweenforwardandreversedirection.
Output
Choice1
Drive
IncrementSpeed
DecrementSpeed
ToggleReverse
ControlOutputs:SelectControlOutputstoactivateoneofeightcontroloutputpinsontheOutputmodule’sDB9
connectororoneoftwooutputsontheOutputmodule’sjacksocket.Outputscanbesettomomentaryortheirstatecan
belatchedwithSet,ClearorToggleactions.
Output
Choice1Choice2
ControlOutputs
Output1
Momentary
Output2Set
Output3
Clear
Output4
Toggle
Output5
Output6
Output7
Output8
Functions:SelectFunctionstogivetheuserinstantaccesstospecicfunctions(drive,seating,utilityetc.)andproles.
Optionsinclude:
•NextFunction:selectsthenextfunctionintheprole.
•PreviousFunction:selectsthepreviousfunctionintheprole.
•NextProle:selectsthenextprole.
•PreviousProle:selectsthepreviousprole.
•NextFunctionofPurpose:selectsthenextfunctionofthesamespeciedtypeintheactiveprole.
•PreviousFunctionofPurpose:selectsthepreviousfunctionofthesamespeciedtypeintheactiveprole.
•ForcetoFunction:selectsaspecicfunction.Thisisconguredbyspecifyingthefunction.
