O-Ring Boss Torque Recommendations
ORS (Face Seal) FITTINGS
(See Figure 8C-3)
Face seal fittings have O-ring grooves machined into
the flat male face. This O-ring and flat surface mate
against the mating fittings machined face.
The swivel nut can be retracted to inspect the O-ring
and fitting face without removal of tubes or compo-
nents.
Figure 8C-3. ORS (Face Seal) Fitting
Replacement O-Ring for ORS (Face Seal) Fittings
O-Ring Face Seal Torque Recommendations
HYDRAULICS
SECTION 8C. GENERAL INSTRUCTIONS
8C-3
8C
SAE
Dash Thread Tube Torque
Size Size O.D. In-Lbs.
3
3
⁄8-24 0.188 96-120
4
7
⁄16-20 0.250 168-192
5
1
⁄2-20 0.312 216-240
6
9
⁄16-18 0.375 288-312
8
3
⁄4-16 0.500 600-720
10
7
⁄8-14 0.625 864-960
12 1
1
⁄16-12 0.750 1500-1620
14 1
3
⁄8-12 0.875 1920-2160
16 1
5
⁄16-12 1.000 2400-2640
20 1
5
⁄8-12 1.250 2520-3360
24 1
7
⁄8-12 1.500 3240-4320
SAE
Dash Thread Tube Torque
Size Size O.D. In-Lbs.
3 N/A N/A
4
9
⁄16-18 0.250 120-144
5 N/A N/A
6
11
⁄16-16 0.375 216-240
8
13
⁄16-16 0.500 384-420
10 1-14 0.625 552-600
12 1
3
⁄16-12 0.750 780-840
16 1
7
⁄16-12 1.000 1104-1200
20 1
11
⁄
16-12 1.250 1500-1680
24 2-12 1.500 1800-3960
ORS (Face Seal) ORS (Face Seal) Jacobsen
Tube Size O-Ring Size Part No.
411339908
612339909
814339910
10 16 339911
12 18 339912
16 21 339913
20 25 339914
24 29 339915
