Jacobsen HR5111 User Manual

GLOW PLUG TEST
See Figure 10L-1 and test a suspected faulty glow plug
as follows:
1. Shut down and allow engine to cool.
2. Disconnect glow plug lead wire.
3. Set multimeter to 200 Ω (ohms) scale.
4. Connect one multimeter test lead to glow plug ter-
minal and the other to housing.
•
The multimeter reading should be approximate-
ly 0.8 Ω (ohms) (cold). If the reading is at infinity
or 0 Ω (ohms) the glow plug is defective and
must be replaced.
ELECTRICAL SYSTEM
SECTION 10L. GLOW PLUGS
10L-1
10L
POWER
OFF ON
200m
2
20
200
1000
750
200
20
2
200m
20M
2M
200M
20K
2K
200
200
DCV
ACV
ACA
200µ
2m
200m
2
2
200m
20m
10A
2m
200µ
DCA
20m
10A
COM A 10A
!
1000V
750V
MAX
!
!
2A
MAX
10A MAX
500V
MAX
200m
2
20
20
2
200m
20M
2M
200M
20K
2K
200
200
ACA
200µ
2m
200m
2
2
200m
20m
10A
2m
200µ
DCA
20m
10A
COM A
!
2A
MAX
-
V -
Figure 10L-1. Glow Plug Test
