CONTENTS
This manual contains repair instructions for major trac-
tor components, attachments and options. The Table of
Contents at the start of each section lists contents of
that section. Sections are identified by tabs in the right
hand margin.
This manual is to be used in conjunction with the Op-
erator’s Manual and Parts Catalog.
Normal maintenance, adjustment, and operating proce-
dures are also covered in the user Operator’s Manual
and are only included where appropriate in this Service
and Repair Manual.
Engine repair is not covered in this manual. Refer to
the appropriate engine manufacturer’s instructions for
engine service and repair.
This manual includes all removal, disassembly, inspec-
tion, repair, reassembly, installation, adjustment, and
testing procedures. If you, as user of this machine, do
not consider yourself or your repair facilities capable of
a given procedure, please consult your dealer or dis-
tributor.
Information, specifications, illustrations, and procedures
in this manual are based on information in effect at the
time this manual was published. Improvements and
product changes due to continual advancements of the
product design may cause changes to your product
that may not be included in this manual. Each manual
is reviewed and updated as required to include changes
and product improvements.
Read each section completely before proceeding with
specific repairs in that section. You will minimize errors
by understanding what you will be doing and how the
component relates to others in its system. Lists of re-
pair tools and materials for each section of the manual
are given at the start of that section.
The designations L.H. (left hand) and R.H. (right hand)
used throughout this manual refer to the operator’s left
or right when standing in the normal operating position.
INDEX NUMBERS
Illustrations showing removal, disassembly, reassembly
and installation may have index numbers to call out the
sequence of procedure.
Where the sequence of procedure is not important or
self-evident (eg. linkages, hoses, clamps, etc.) index
numbers are not included.
Repair procedures for items not subject to wear (eg.
panels, brackets, frames) are not included in this man-
ual except for the general procedures given below.
Exercise common sense during disassembly or reas-
sembly; remove only the items required to accomplish
necessary repair or service.
REPLACEMENT PARTS
Use the appropriate Parts Catalog when ordering re-
placement parts. Follow installation instructions shipped
with service parts or kits. When ordering parts, always
give the serial number and product number of your
machine as well as quantity, part number and descrip-
tion of the parts needed.
To eliminate error and speed delivery:
1. Write your NAME and ADDRESS on your order
plainly.
2. Explain WHERE and HOW to make shipment.
3. Give PRODUCT NUMBER, NAME, and SERIAL
NUMBER that is stamped on the NAME and SERI-
AL PLATE of your product.
4. Order by QUANTITY DESIRED, the PART NUM-
BER and the DESCRIPTION OF PART.
5. Send your order to or visit your nearest AUTHO-
RIZED JACOBSEN TURF EQUIPMENT DISTRIB-
UTOR.
6. INSPECT ALL SHIPMENTS ON RECEIPT. If any
parts are damaged or missing, file a claim with the
carrier before accepting.
7. Do not return material to your AUTHORIZED JA-
COBSEN DISTRIBUTOR without a letter of expla-
nation. Make a list of all returned parts, show your
name and address, and include it with the ship-
ment. TRANSPORTATION CHARGES MUST BE
PREPAID.
SERIAL NUMBERS
See Figure 1A-1 for location of tractor assembly serial
number.
Figure 1A-1. Serial Number Location
INTRODUCTION
SECTION 1A. GENERAL INFORMATION
1A-1
