Table 43: Rack Requirements and Specifications for an M7i Router (continued)
GuidelinesRack Requirement
•
Secure the rack to the building structure.
•
If earthquakes are a possibility in your geographical area, secure the rack to the
floor.
•
Secure the rack to the ceiling brackets as well as wall or floor brackets for maximum
stability.
Rack connection to the building
structure
CAUTION: If you are front-mounting the chassis, we recommend supporting
the back of the router with a shelf or other structure.
Figure 23: Typical Open-Frame Rack
Related
Documentation
Installation Safety Warnings for Juniper Networks Devices on page 233•
• M7i Router Clearance Requirements for Airflow and Hardware Maintenance on page 77
• M7i Router Physical Specifications on page 74
• M7i Router Site Preparation Checklist on page 73
Copyright © 2019, Juniper Networks, Inc.76
M7i Multiservice Edge Router Hardware Guide
