throughput is supported, but constitutes oversubscription of the FPC. The fixed interface
card (FIC) has a maximum throughput of 1 Gbps full duplex.
PICs are hot-removable and hot-insertable.
Most PICs supported on the M7i router have the following components.
•
One or more cable connector ports—Accept a network media connector.
•
LEDs—Indicate PIC and port status. Most PICs have an LED labeled STATUS on the
PIC faceplate. Some PICs have additional LEDs, often one per port. The meaning of
the LED states differs for various PICs.
•
Ejector lever—Controls the locking system that secures the PIC in the card cage.
Related
Documentation
M7i PICs Supported on page 47•
• M7i PIC LEDs on page 47
• M7i Field-Replaceable Units (FRUs) on page 135
• M7i Flexible PIC Concentrators (FPCs) Description on page 43
• PIC Serial Number ID Label on page 214
• Replacing an M7i PIC on page 159
• Troubleshooting the M7i FIC or PICs on page 205
M7i PIC LEDs
LEDs indicate PIC and port status. Most PICs have an LED labeled STATUS on the PIC
faceplate. Some PICs have additional LEDs, often one per port. The meaning of the LED
states differs for various PICs. For more information, see the M7i Multiservice Edge Router
Interface Module Reference.
Related
Documentation
M7i PICs Description on page 46•
• Installing an M7i PIC on page 161
• PIC Serial Number ID Label on page 214
• Replacing an M7i PIC on page 159
• Troubleshooting the M7i FIC or PICs on page 205
M7i PICs Supported
Table 36 on page 48 lists the PICs supported by the M7i router. The PICs are listed
alphabetically by PIC family.
47Copyright © 2019, Juniper Networks, Inc.
Chapter 6: Line Card Components and Descriptions
