Figure 53: Installing the SDRAM Module
See Also M7i Chassis Description on page 11•
• M7i Midplane Description on page 12
• Removing an SDRAM Module on page 153
Related
Documentation
M7i Chassis Description on page 11•
• M7i Midplane Description on page 12
• Maintaining the M7i Routing Engine on page 192
Removing and Inserting the PC Card
The slot labeled PC CARD on the Routing Engine faceplate accepts a Type I PC card, as
defined in the PC Card Standard published by the Personal Computer Memory Card
International Association (PCMCIA). You can also copy Junos OS from the Routing Engine
onto a PC card, for example, to create a backup copy of upgrade software that you have
obtained from Juniper Networks. Instructions for copying software to a PC card are
available at the Juniper Networks Customer Support Center Web site
(https://www.juniper.net/support); after logging in, navigate to the download page for
Junos OS.
The following Compact Flash are supported on the M7i Router:
•
Sandisk (SDCFJ-1024-388)
•
Unigen (UGB30SHS1000C3JN)
•
Western Digital (SSD-C01G-3502)
155Copyright © 2019, Juniper Networks, Inc.
Chapter 23: Replacing Host Subsystem Components
