Juniper M7i - Figure 33: Console and Auxiliary Serial Port Connector

NOTE:
For console devices, configure the serial port to the following values:
•
Baud rate—9600
•
Parity—N
•
Data bits—8
•
Stop bits—1
•
Flow control—none
3. Tighten the screws on the connector.
NOTE:
For console devices, configure the serial port to the following values:
•
Baud rate—9600
•
Parity—N
•
Data bits—8
•
Stop bits—1
•
Flow control—none
Figure 33: Console and Auxiliary Serial Port Connector
See Also Initially Configuring the M7i Router on page 129•
• Connecting Power to an AC-Powered M7i Router on page 123
• Connecting Power to a DC-Powered Router on page 124
Related
Documentation
Routing Engine Interface Cable and Wire Specifications for the M7i Router on page 97.•
• M7i Power System Description on page 59
117Copyright © 2019, Juniper Networks, Inc.
Chapter 18: Connecting the M7i to External Devices
