CHAPTER 15
Unpacking the M7i
•
Tools and Parts Required to Unpack the M7i Router on page 105
•
Unpacking the M7i Router on page 105
•
Verifying the M7i Router Parts Received on page 107
Tools and Parts Required to Unpack the M7i Router
To unpack the router and prepare for installation, you need the following tools:
•
Phillips (+) screwdriver, number 2
•
1/2-in. or 13-mm open-end or socket wrench to remove bracket bolts from the shipping
pallet
•
Blank panels to cover any slots not occupied by a component
Related
Documentation
M7i Router Description on page 3•
• M7i Chassis Description on page 11
• M7i Chassis Lifting Guidelines on page 233
Unpacking the M7i Router
The router is shipped in a cardboard carton, secured with foam packing material. The
carton also contains an accessory box and the M7i Internet Router Installation Quick
Start.
NOTE: The router is maximally protected inside the shipping carton. Do not
unpack it until you are ready to begin installation.
To unpack the router, perform these steps (see Figure 28 on page 106):
1. Move the shipping carton to a staging area as close to the installation site as possible,
but where you have enough room to remove the system components.
2. Position the carton so that the arrows are pointing up.
