The following drive has been verified to work in the RE-B-1800 Routing Engines:
•
SSD SLC 64 GB
To replace a storage drive:
1. Disable and deactivate the storage drive.
2. Remove the storage drive.
a. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and
connect the strap to an ESD point on the appliance.
b. Unfasten the thumbscrew that secures the access door in front of the storage drive
slots, and open the door.
c. Slide the lock on the ejector to the unlocked position.
d. Carefully slide the drive out of the slot.
3. Reinstall the storage drive.
a. Carefully align the sides of the drive with the guides in the slot.
b. Slide the drive into the slot until you feel resistance, carefully ensuring that it is
correctly aligned.
c. Close the access door and tighten the thumbscrew to secure the door.
4. Mount the new storage drive.
Related
Documentation
Returning a Hardware Component to Juniper Networks, Inc. on page 217•
Replacing the Routing Engine Interface Port Cables
The Routing Engine is located on the front of the router, as shown in Figure 5 on page 11.
It houses the Routing Engine interface ports, which accept connections to external
management devices.
To replace the cables connecting to the Routing Engine interface ports, perform the
following procedures:
•
Replacing the Management Ethernet Cable on page 145
•
Replacing the Console or Auxiliary Cable on page 145
Copyright © 2019, Juniper Networks, Inc.144
M7i Multiservice Edge Router Hardware Guide
