PIC 0 REV 11 750-002971 DC5173 4x OC-3 SONET, MM
PIC 1 REV 12 750-005633 HN0432 1x CHOC12 IQ SONET, SMIR
PIC 3 REV 14 750-014895 DE6782 MultiServices 100
FPC 1 E-FPC
PIC 2 BUILTIN BUILTIN 1x Tunnel
PIC 3 REV 09 750-009099 PP8480 1x G/E, 1000 BASE
Xcvr 0 REV 01 740-011782 PBE2BU8 SFP-SX
Fan Tray Rear Fan Tray
Most components also have a small rectangular serial number ID label (see
Figure 69 on page 214) attached to the component body.
Figure 69: Serial Number ID Label
Related
Documentation
CFEB and CFEB-E Serial Number ID Label on page 216•
• PIC Serial Number ID Label on page 214
• Power Supply Serial Number ID Label on page 215
• Routing Engine Serial Number ID Label on page 214
• Contacting Customer Support on page 211
Routing Engine Serial Number ID Label
The serial number ID label for a Routing Engine is located on the left side near the midplane
connector. Some Routing Engines might have more than one serial number. Contact your
Juniper Networks support representative if you need assistance in determining which
serial number to provide.
Related
Documentation
M7i Routing Engine Description on page 17•
• Maintaining the M7i Routing Engine on page 192
• Replacing the M7i Routing Engine on page 141
• Contacting Customer Support on page 211
PIC Serial Number ID Label
The serial number ID label for a PIC is located on the right side of the PIC, as shown in
Figure 70 on page 215.
Copyright © 2019, Juniper Networks, Inc.214
M7i Multiservice Edge Router Hardware Guide
