MLPPP
•
MLFR
•
cRTP
•
Multiclass MLPPP
•
RPM
NOTE: You can enable either Layer 2 or Layer 3 services on the MultiServices
Module, but youcannotenable both Layer 2 and Layer3 services concurrently.
The configuration for these services comprises a series of rules that you can arrange in
order of precedence as a rule set. Each rule follows the structure of a firewall filter, with
a from statement containing input or match conditions and a then statement containing
actions to be taken if the match conditions are met.
For information about configuring interfaces on the MSM, see the Junos OS Services
Interfaces Library for Routing Devices.
Related
Documentation
M7i CFEB and CFEB-E LEDs on page 69•
• M7i and M10i Packet Forwarding Engine Architecture on page 5
• M7i Router Description on page 3
• M7i Router Physical Specifications on page 74
M7i CFEB and CFEB-E LEDs
Table 40: States for CFEB or CFEB-E LEDs
DescriptionStateColorLabel
CFEB/CFEB-E is running normally.On steadilyGreenOK
CFEB-E is starting upBlinking
CFEB/CFEB-E is offline.Off
CFEB/CFEB-E is not operational or is in reset mode.On steadilyRedFAIL
CFEB/CFEB-E is functioning properly.Off
CFEB/CFEB-E is functioning as master. On an M7i
router, this LED is always lit.
On steadilyBlueMASTER
Related
Documentation
• M7i Compact Forwarding Engine Board (CFEB) and Enhanced Compact Forwarding
Engine Board (CFEB-E) Description on page 63
69Copyright © 2019, Juniper Networks, Inc.
Chapter 8: Switch Fabric Components and Descriptions
