Juniper M7i Hardware Guide

NOTE: The M7i router is now end-of-life. See the JTAC support bulletin
TSB16809 for additional information about the PICs and other associated
FRUs that moved to end-of-life with the router. The “M7i End-of-Life PICs
Supported” on page 50 topic lists PICs that moved to end-of-life before the
M7i router itself moved to end-of-life.
Table 36: PICs Supported in the M7i Router
First
Junos OS
Release
SupportConnectorModel NumberPortsPIC Family and Type
ATM2 IQ
6.1Coaxial:
•
10 ft (3.05 m) posilock SMB to
BNC (provided)
•
Four pairs of Rx and Tx coaxial
cables
PE-4DS3-ATM24ATM2 DS3 IQ PIC (M7i Router)
6.0
•
Optical: SC/PCPE-2OC3-ATM2-MM
PE-2OC3-ATM2-SMIR
2ATM2 OC3/STM1 IQ PIC (M7i
Router)
6.0
•
Optical: SC/PCPE-1OC12-ATM2-MM
PE-1OC12-ATM2-SMIR
1ATM2 OC12/STM4 IQ PIC (M7i
Router)
Channelized IQE
10.2
•
Standard DS3 BNC coaxial cable
interfaces
PE-4CHDS3-E3-IQE-BNC4Channelized DS3 and E3 Enhanced
IQ (IQE) PIC (M7i Router)
10.2
•
120-ohm RJ-48C connector
(female)
PE-10CHE1-T1-IQE-RJ4810Channelized E1/T1 Enhanced IQ
(IQE) PIC (M7i Router)
10.2
•
Optical: LC/PCPE-2CHOC3-STM1-IQE-SFP2Channelized OC3/STM1 Enhanced
IQ (IQE) PIC with SFP (M7i Router)
10.2
•
Optical: LC/PCPE-1CHOC12STM4-IQE-SFP1Channelized OC12/STM4 Enhanced
IQ (IQE) PIC with SFP (M7i Router)
Circuit Emulation
9.3
•
Optical: LC/PCPE-4CHOC3-CE-SFP4Channelized OC3/STM1 Circuit
Emulation PIC with SFP (M7i
Router)
9.3
•
RJ-21 connector
•
Cables are rated for intra-building
connections only.
PE-12T1E1-CE-TELCO12E1/T1 Circuit Emulation PIC (M7i
Router)
Copyright © 2019, Juniper Networks, Inc.48
M7i Multiservice Edge Router Hardware Guide
