Keithley 2001

SCPI Conformance Information
J-16
:SOURce
:TTL[1][:LEVel] <b>
:TTL[1][:LEVel]?
:TTL2[:LEVel] <b>
:TTL2[:LEVel]?
:TTL3[:LEVel] <b>
:TTL3[:LEVel]?
:TTL4[:LEVel] <b>
:TTL4[:LEVel]?
:STATus
:MEASurement
[EVENt]?
:ENABle <NRf>
:ENABle?
:PTRansition <NRf>
:PTRansition?
:NTRansition <NRf>
:NTRansition?
:CONDition?
:QUEue
:DISable <list>
:DISable?
:CLEar
:SYSTem
:POSetup <name>
:POSetup?
:FRSWitch?
:AZERo
:TYPE <name>
:TYPE?
:STATe <b>
:STATe?
:AMEThod <name>
:AMEThod?
:LSYNc
:STATe <b>
:STATe?
:CLEar
:TRACe|:DATA
:CLEar [BUFFER,]
:EGRoup [BUFFER,] <name>
:EGRoup? [BUFFER,]
:FEED [BUFFER,]
:PRETrigger
:AMOunt
[:PERCent] [BUFFER,] <n>
[:PERCent]? [BUFFER,]
:READings [BUFFER,] <n>
:READings/ [BUFFER,]
:SOURce [BUFFER,] <name>
:SOURce? [BUFFER,]
Set digital output line #1 true (1 or ON) or false (0 or OFF).
Query digital output line 1.
Set digital output line #2 true (1 or ON) or false (0 or OFF).
Query digital output line 2.
Set digital output line #3 true (1 or ON) or false (0 or OFF).
Query digital output line 3.
Set digital output line #4 true (1 or ON) or false (0 or OFF).
Query digital output line 4.
Path to control measurement event registers:
Read the event register.
Program the enable register.
Read the enable register.
Program the positive transition register.
Read the positive transition register.
Program the negative transition register.
Read the negative transition register.
Read the condition register.
Path to access error queue:
Specify messages not to be placed in queue.
Read the disabled messages.
Clears all messages from Error Queue.
Select power-on setup: RST, PRESet, SAV0-SAV9.
Query power-on setup.
Query INPUTS switch (0 = rear, 1 = front).
Path to set up auto-zero.
Select auto-zero mode: NORMal, SYNChronous.
Query auto-zero mode (0 or 1).
Enable (1 or ON) or disable (0 or OFF) auto-zero.
Query auto-zero (0 or 1).
Select reading acquisition method: BURSt, NORMal, ASTReam, SSTReam.
Query acquisition method.
Path to control line synchronization of measurements.
Enable (1 or ON) or disable (0 or OFF) line sync.
Query line sync (0 or 1).
Clears messages from the Error Queue.
Use :TRACe or :DATA as root command.
Clear readings from buffer.
Select element group: FULL, COMPact.
Query element group.
Select source of readings: SENSe[1], CALCulate[1], NONE.
Path to configure pre-trigger storage mode.
Path to specify number of pre-trigger readings.
Specify as a % (0 to 100) of buffer.
Query percentage.
Specify as a number.
Query number of readings.
Select pre-trigger source event: EXTernal, TLINk, BUS, MANual.
Query pre-trigger source event.
Table J-2 (cont.)
Syntax of non-SCPI commands implemented by Model 2001
Command Description
