Keithley 2001

SCPI Conformance Information
J-17
:ARM[;SEQuance[1]]
[:LAYer[1]]
:TCONfigure
:ASYNchronous
:ILINE <NRf>
:ILINe?
:OLINe <NRf>
:OLINe?
:LAYer2
:TCONfigure
:DIRection <name>
:DIRection?
:ASYNchronous
:ILINe <NRf>
:ILINe?
:OLINe <NRf>
:OLINe?
:TRIGger[:SEQuence[1]]
:TCONfigure
:PROTocol <name>
:PROTocol?
:DIRection <name>
:DIRection?
:ASYNchronous
:ILINe <NRf>
:ILINe?
:OLINe <NRf>
:OLINe?
:SSYNchronous
:LINE <NRf>
:LINE?
:UNIT
:VOLTage
:AC <name>
:DB
:REFerence <n>
:REFerence?
:DBM
:IMPedance <n>
:IMPedance?
:AC?
Path to configure asynchronous Trigger Link:
Select input line (1 to 6).
Query input line.
Select output line (1 to 6).
Query output line.
Path to program arm layer 2:
Path to configure Triggers:
Enable (SOUR) or disable (ACC) Bypass: SOURce, ACCeptor.
Query direction.
Path to configure asynchronous Trigger Link:
Select input line (1 to 6).
Query input line.
Select output line (1 to 6).
Query output line.
Path to program trigger layer:
Path to configure Triggers:
Select protocol: ASYNchronous, SSYNchronous.
Query protocol.
Enable (SOUR) or disable (ACC) Bypass: SOURce, ACCeptor.
Query direction.
Path to configure asynchronous Trigger Link:
Select input line (1 to 6).
Query input line.
Select output line (1 to 6).
Query output line.
Path to configure semi-synchronous Trigger Link:
Select trigger line (1 to 6).
Query trigger line.
Path to configure ACV units.
Select ACV measurement units: V, DB, DBM.
Path to set DB reference voltage.
Specify reference in volts.
Query DB reference.
Path to set DBM reference impedance.
Specify reference impedance.
Query DBM reference impedance.
Query ACV units.
Table J-2 (cont.)
Syntax of non-SCPI commands implemented by Model 2001
Command Description
