1-4 Keysight B1505A Configuration and Connection Guide
Configuration Guide
Measurement Resources
Table 1-1 B1505A Measurement Resource Selection Guide
Measurement Resource Required Module/Expander Main Specification
High Power SMU B1510A HPSMU • Up to 200 V, 1A force
• 10 fA current resolution
Medium Power SMU B1511B MPSMU • Up to 100 V, 100 mA force
• 10 fA current resolution
High Current SMU B1512A HCSMU • 20 A/20 V (Pulsed); 1A/40 V (DC)
High Voltage SMU B1513C HVSMU • 1500 V/8 mA;3000 V/4 mA (Pulsed &
DC)
Medium Current SMU B1514A MCSMU • 1 A/30 V (Pulsed); 100 mA/30 V (DC)
Ultra High Current Unit N1265A Ultra High Current
Expander/Fixture and two units
of B1514A MCSMU/B1512A
HCSMU
• 1500 A/60 V (Pulsed), 22.5 kW peak
power
• 500 A/60 V (Pulsed), 7.5 kW peak power
High Voltage Medium
Current Unit
N1266A HVSMU Current
Expander, B1513C HVSMU
and two units of B1514A
MCSMU/B1512A HCSMU
• 1500 V / 2.5 A (Pulsed), 2200 V/ 1.1 A
(Pulsed)
Ultra High Voltage Unit N1268A Ultra High Voltage
Expander and two units of
B1514A MCSMU or a
combination of a B1512A
HCSMU and a B1514A
MCSMU
• 10 kV/20 mA (Pulsed);10 kV/10 mA
(DC)
Multi Frequency CMU B1520A MFCMU • 1 kHz to 5 MHz
•0 to ±25 V using internal DC bias
•0 to± 3000 V using HVSMU and High
Voltage Bias-Tee
