Keysight B1505A Configuration and Connection Guide 7-13
Connection and Ordering Examples
Package Device Measurement Configuration Examples
NOTE This configuration is equivalent to the B1505AP-U50 10 kV / 500 A / Fixture Pack or
B1505AP-U70 10kV / 1500 A / Fixture Pack configuration.
16493V 1 10 kV Ultra High Voltage Cable
16493V-001 1 10 kV Ultra High Voltage Cable (1.5 m)
N1254A 1 Accessories for instruments and fixtures
N1254A-508 4 Banana to Banana Cable 250 mm (red, 1ea)
N1254A-509 4 Banana to Banana Cable 250 mm (black, 1ea)
N1254A-510 3 Dolphin Clip 2ea (red and black)
N1254A-520 1 10 kV Ultra High Voltage Open End Cable, 1 m (pair)
N1262A 1 R-box for B1505A
N1262A-036 1 50 Ohm Termination Adapter
1251-2277 1 Banana to BNC Adapter
Model/Option Quantity Description
To Next Page
