7-32 Keysight B1505A Configuration and Connection Guide
Connection and Ordering Examples
Configuration Examples for Lateral Device Measurement with Wafer Prober
N1260A-STD 1 High Voltage Bias-Tee
16493S 1 High Current Source Monitor Unit Cable
16493S-011 1 High Current Source Monitor Unit non-Kelvin Adapter
N1261A 1 Protection Adapter
N1261A-003 1 Protection Adapter for High Power Source Monitor Unit (HV-Triaxial output)
N1262A 1 R-box for B1505A
N1262A-010 1 1 kohm R-box for gate (Triaxial output)
N1262A-036 1 50 Ohm Termination Adapter
N1254A 1 Accessories for instruments and fixtures
N1254A-104 2 Triax (f) to BNC (m) adapter
N1256A-518 3 SHV Cable 1.5 m
Model/Option Quantity Description
