Keysight B1505A Configuration and Connection Guide 7-55
Connection and Ordering Examples
Configuration Examples for Vertical Device Measurement with Wafer Prober
Table 7-26 Required equipment, accessories, and cables
Model/Option Quantity Description
B1505A 1 Power Device Analyzer/Curve Tracer mainframe
B1511B-FG 1 Medium Power Source/Monitor Unit module (100 V/ 100 mA)
B1512A-FG 1 High Current Source Monitor Unit, 20 A/20 V(Pulsed); 1 A/40 V(DC)
B1513C-FG 1 High Voltage Source Monitor Unit, 3000 V/4 mA (Pulsed & DC)
B1514A-FG 1 Medium Current Source Monitor Unit, 1 A/30 V(Pulsed), 100 mA/30 V(DC)
16493U 1 High Current BNC Coaxial Cable
16493U-001 2 High Current BNC Coaxial Cable (1.5 m)
16494A 1 Triaxial Cable
16494A-003 1 Triaxial Cable (80 cm)
1250-2405 1 BNC-T Plug (m)-BNC (f)-BNC (f) adapter, 1ea
N1258A 1 Module Selector for B1505A
16493S 1 High Current Source Monitor Unit Cable
16493S-011 1 High Current Source Monitor Unit non-Kelvin Adapter
N1262A 1 R-box for B1505A
N1262A-010 1 1 kohm R-box for gate (Triaxial output)
N1262A-036 1 50 Ohm Termination Adapter
N1254A 1 Accessories for instruments and fixtures
N1254A-104 2 Triax (f) to BNC (m) adapter
To Next Page
