Keysight B1505A Configuration and Connection Guide 7-61
Connection and Ordering Examples
Configuration Examples for Vertical Device Measurement with Wafer Prober
Table 7-29 Ordering example
Model/Option Quantity Description
B1505A 1 Power Device Analyzer/Curve Tracer mainframe
B1513C-FG 1 High Voltage Source Monitor Unit, 3000 V/4 mA (Pulsed & DC)
B1514A-FG 3 Medium Current Source Monitor Unit, 1 A/30 V(Pulsed), 100 mA/30 V(DC)
B1520A-FG 1 Multi Frequency Capacitance Measurement Unit Module
N1265A 1 Ultra High Current Expander/Fixture
N1265A-001 1 Ultra High Current Expander/Fixture
N1260A 1 High Voltage Bias-Tee
N1260A-STD 1 High Voltage Bias-Tee
N1254A 1 Accessories for instruments and fixtures
N1254A-518 3 SHV Cable 1.5 m
N1254A-524 1 Ultra High Current Prober System Cable
N1262A 1 R-box for B1505A
N1262A-021 1 Universal R-Box, HV Triaxial to SHV
N1262A-036 1 50 Ohm Termination Adapter
