Keysight B1505A Configuration and Connection Guide 7-69

Connection and Ordering Examples

GaN Current Collapse / Dynamic On-Resistance Measurement System using the N1267A

N1254A 1 Accessories for instruments and fixtures

N1254A-507 1 HVSMU Coaxial Cable Assy 1.5 m

N1254A-104 1 Triax (m) to BNC (f) adapter

16493U 1 High Current BNC Coaxial Cable

16493U-001 1 High Current BNC Coaxial Cable (1.5 m)

N1262A 1 R-box for B1505A

N1262A-036 1 50 Ohm Termination Adapter

1251-2277 1 Adapter-BNA BNC Jack Black
