Keysight Technologies B1505A Configuration Guide

1-32 Keysight B1505A Configuration and Connection Guide
Configuration Guide
N1268A Ultra High Voltage Expander
N1268A-UK6 Commercial cal. Certificate with test data
Related accessories for package device testing
N1265A-040 10 kV Ultra High Voltage Gate Protection
Adapter
• The N1265A-040 adapter is used with the
N1265A UHC Expander/Fixture for
package device testing.
• This adapter is used to protect a B1514A
MCSMU module used as a Gate driver
SMU from device breakdown when
making ultra high voltage measurement
with the N1268A.
Related accessories for on-wafer device testing
N1269A Ultra High Voltage Connection Adapter • The N1269A adapter is used to protect
measurement resources from unexpected
surge when connecting the N1268A Ultra
High Voltage Expander to a wafer prober.
• Protection adapter for the B1514A
MCSMU is included in the N1269A
adapter.
• This adapter supports the B1514A
MCSMU only.
Model/Option Description Additional Information
