Keysight B1505A Configuration and Connection Guide 1-73
Configuration Guide
Upgrade Kit for N1265AU Test Fixture
NOTE Keysight Technologies service center is responsible for N1265AU-015 installation.
NOTE For Keysight field team, installation fee (R-51U-501 or R1286A-HU) will be
automatically added to the N1265AU when making a quotation with Keysight order
configuration tool.
N1254A-522 1500 A Ultra High Current Banana to
Banana Cable, 2 ea.
• Maximum voltage and current is 3 kV and 1500
A.
• The N1265AU-010 500 A Ultra High Current
3-pin Inline Package Socket Module is furnished
with N1254A-522 cables.
N1254A-523 1500 A Ultra High Current Banana to
Open End Cable, 1 m, 2 ea
• Maximum voltage and current is 3 kV and 1500
A.
16493G-001 Digital I/O control cable (1.5 m) • The N1266A is furnished with a 16493G-001
cable.
• Cable length 1.5 m or 3.0 m can be specified by
option 001 or 002.
16493G-002 Digital I/O control cable (3.0 m)
Model/
Option
Description Note
