Keysight Technologies B1505A Configuration Guide

Keysight B1505A Configuration and Connection Guide 2-7
N1259A Connection Guide
Input Connection
Table 2-4 To Connect between B1505A and N1259A for using HVMCU (N1266A)
B1505A terminals Required cables
N1266A terminals
1
1. To configure HVMCU, the N1266A current expander is required.
GNDU
16493L-001 GNDU cable, 1.5 m, 1 ea.
GNDU
HVSMU
Force 16493T-001 HVSMU cable, 1.5 m, 1 ea. HVSMU
MCSMU
2
2. HCSMU is substitutable. Then use 16493S HCSMU cable, N1254A-103 adapter for Force, and
N1254A-517 adapter for Sense.
Force 16494A-001 Triaxial cable, 1.5 m, 1 ea.
I Control
Force
Sense 16494A-001 Triaxial cable, 1.5 m, 1 ea. Sense
MCSMU
2
Force 16494A-001 Triaxial cable, 1.5 m, 1 ea.
V Control
Force
Sense 16494A-001 Triaxial cable, 1.5 m, 1 ea. Sense
Digital I/O 16493G-001 Digital I/O connection cable, 1.5 m, 1 ea. Digital I/O Input
N1266A terminals Required cables N1259A terminals
Output High 16493T-001 HVSMU cable, 1.5 m, 1 ea. HVSMU1 or 2
Low 16493L-001 GNDU cable, 1.5 m, 1 ea.
GNDU1 or 2
Digital I/O Output 16493G-001 Digital I/O connection cable, 1.5 m, 1 ea.
Digital I/O
1
1. This connection is required if the module selector (N1259A-300) is used.
LINE Power cable, 1 ea., for connecting to power line 
