2-6 Keysight B1505A Configuration and Connection Guide
N1259A Connection Guide
Input Connection
Table 2-2 To Connect between B1505A and N1259A for using Module Selector (N1259A-300)
Table 2-3 To Connect between B1505A and N1259A for using Fast Switch (N1267A)
B1505A terminals Required cables N1259A terminals
GNDU
16493L GNDU cable, 3 m or 1.5 m, 1 ea.
GNDU2
1
1. If the N1266A expander is used, connect the 16493L-001 cable from the N1266A Output Low.
HVSMU
Force 16493T HVSMU cable, 3 m or 1.5 m, 1 ea.
HVSMU2
2
2. If the N1266A expander is used, connect the 16493T-001 cable from the N1266A Output High.
HCSMU
or
DHCSMU
Force For HCSMU, 16493S HCSMU cable, 3 m or 1.5 m, 1 ea.
For DHCSMU, 16493S HCSMU cable, 3 m or 1.5 m, 1 ea., and
16493S-021 Dual HCSMU adapter. See "To Connect
16493S-021" on page 5-22 for Dual HCSMU adapter.
HCSMU3
Force
Sense Sense
HPSMU
or
MPSMU
Force 16494A Triaxial cable, 3 m or 1.5 m, 1 ea., for the non-Kelvin
connection, connect it between the Force connectors.
For the Kelvin connection, prepare additional one more cable and
connect it between the Sense connectors. Or use 16493K Kelvin
triaxial cable instead of 16494A.
HPSMU3
Force
Sense Sense
Digital I/O 16493G Digital I/O connection cable, 3 m or 1.5 m, 1 ea.
Digital I/O
3
3. If the N1266A expander is used, connect the 16493G-001 cable from the N1266A Digital I/O Output.
Power cable, 1 ea., for connecting to power line LINE
B1505A terminals Required cables N1267A terminals
MCSMU
Force 16494A Triaxial cable, 3 m or 1.5 m, 1 ea. MCSMU Force
Sense 16494A Triaxial cable, 3 m or 1.5 m, 1 ea. Sense
HCSMU
Force 16493S HCSMU cable, 3 m or 1.5 m, 1 ea. for HCSMU
HCSMU
Force
Sense Sense
HVSMU
Force 16493T HVSMU cable, 3 m or 1.5 m, 1 ea.
HVSMU
GNDU
16493L GNDU cable, 3 m or 1.5 m, 1 ea.
GNDU
N1267A terminals Required cables/Description N1259A terminals
High
Force 16493T-001 HVSMU cable, 1.5 m, 1 ea. HVSMU1
Low
Force 16493U-001 HVSMU cable, 1.5 m, 1 ea. AUX 1 or 2
