Keysight B1505A Configuration and Connection Guide 2-5
N1259A Connection Guide
Input Connection
Table 2-1 To Connect between B1505A and N1259A, without HVMCU and Module Selector
B1505A terminals Required cables N1259A terminals
Interlock
16493J Interlock cable, 3 m or 1.5 m, 1 ea.
Interlock
GNDU
16493L GNDU cable, 3 m or 1.5 m, 1 ea.
GNDU1
1
1. If the N1266A expander is used, connect the 16493L-001 cable from the N1266A Output Low.
HVSMU
Force 16493T HVSMU cable, 3 m or 1.5 m, 1 ea.
HVSMU1
2
2. If the N1266A expander is used, connect the 16493T-001 cable from the N1266A Output High.
HCSMU
or
DHCSMU
Force For HCSMU, 16493S HCSMU cable, 3 m or 1.5 m, 1 ea.
For DHCSMU, 16493S HCSMU cable, 3 m or 1.5 m, 1 ea., and
16493S-021 Dual HCSMU adapter. See "To Connect
16493S-021" on page 5-22 for Dual HCSMU adapter.
HCSMU1
or
HCSMU2
Force
Sense Sense
MCSMU Force 16494A Triaxial cable, 3 m or 1.5 m, 1 ea. and N1254A-104
Triaxial(f)-BNC(m) adapter, 1 ea.
HCSMU1
or
HCSMU2
Force
Sense 16494A Triaxial cable, 3 m or 1.5 m, 1 ea. Sense
HPSMU
or
MPSMU
Force 16494A Triaxial cable, 3 m or 1.5 m, 1 ea., for the non-Kelvin
connection, connect it between the Force connectors.
For the Kelvin connection, prepare additional one more cable and
connect it between the Sense connectors. Or use 16493K Kelvin
triaxial cable instead of 16494A.
HPSMU1
or
HPSMU2
Force
Sense Sense
MFCMU Hpot/
Hcur
N1300A CMU cable, 3 m or 1.5 m, 1 ea.
BNC(m)-(f)-(f) adapter, total 2 ea., 1 ea. for connecting Hpot,
Hcur, and AUX1, and 1 ea. for connecting Lpot, Lcur, and
AUX2.
It is not needed to connect the ground wire extended from the
CMU cable.
AUX 1
Lpot/
Lcur
AUX 2
MFCMU Hpot N1300A CMU cable, 3 m or 1.5 m, 1 ea.
It is not needed to connect the ground wire extended from the
CMU cable.
MFCMU
Only for
N1259A-
020
Hpot
Hcur Hcur
Lcur Lcur
Lpot Lpot
BNC cable, for connecting instruments other than the B1505A AUX 1 or 2
To Next Page
