N9030B PXA Signal Analyzer Service Guide 403
Replaceable Parts
Hardware
Table 15-8 RF Area (Options 503, 508, 513, 526)
Item Description Keysight Part Number
1 A9 RF Attenuator A (0-4 dB) (Options 503, 508, 513, 526) 33360-60008
2 A10 RF Attenuator B (0-66 dB) (Options 503, 508, 513, 526) 33321-60083
3 A11 Low Band Switch Assembly E4410-60121
4 A12 YTF Preselector (Options 503, 508, 513, 526) 5087-7382
5 A20 YTO Assembly N9020-60009
W2 Cable, semi-rigid, RF Input to Attenuator A (Options 503, 508, 513, 526) N9020-20100
W3 Cable, semi-rigid, Cal In to attenuator, Reference Assy J701 to
Attenuator A (Options 503, 508, 513, 526)
N9020-20023
W4 Cable, semi-rigid, Attenuator B to Attenuator A (Options 503, 508, 513,
526)
N9020-20025
W5 Cable, Ribbon, Attenuator A/B to Front End Controller J800 E4410-60157
W6 Cable, semi-rigid, Attenuator B to Low Band Switch (Options 503, 508,
513, 526 without Option MPB or LNP)
N9020-20024
W7 Cable, ribbon, Lowband Switch J4 to Front End Controller J700 N9020-60092
W8 Cable, semi-rigid, Front End assy J2 to Low Band Switch J2 (Options
503, 508, 513, 526)
N9020-20101
W20 Cable, semi-rigid, Front End Assy J4 To YTO (Options 503, 508, 513, 526
- without EP0)
N9020-20018
W56 Cable, semi-rigid, Low band Switch assy J3 to YTF input (Options 503,
508, 513, 526 without Option MPB or LNP)
N9020-20123
W57 Cable, semi-rigid, YTF output to Front End assy J9 (Options 503, 508,
513, 526 without Option MPB or LNP)
N9020-20124
