6: Context sensitive help
99
and send data out to a configured IP address and
port. This way no port has to be opened in the
firewall to allow clients to connect to the receiver.
Furthermore since the data stream is now sent to a
PC port, the number of connections to the data
stream is not limited by the receiver.
NTRIP server (source)
This mode allows the receiver to act as Ntrip Server,
and to provide data to an Ntrip Caster.
In terms of TCP/IP, the Ntrip server mode is in fact a
TCP client mode. As an Ntrip Server, the receiver
connects to a caster and starts to stream data.
Serial port
The receiver streams data out of the physical serial
port.
Radio
The receiver streams data using an attached radio.
GSM / Modem / CDMA -
dial up
The receiver streams data using an attached GSM,
Modem or CDMA dial up service.
Bluetooth
GR25/50:
The receiver streams data via the Bluetooth serial
port. This data stream can only be connected to if
the Bluetooth device is activated in Receiver setup:
Network connections, Bluetooth tab. tab.
Press to go back to the previous wizard step. Press to continue to the next wizard step.
Press to cancel and return to GNSS management: Outgoing data stream.
Outgoing data stream wizard: Configure TCP/IP server
Background Information
The receiver works as a TCP server allowing TCP clients to connect to the receiver's ports to receive the data streams.
Setting Descriptions
The table below describes the settings that can be configured on the Configure TCP/IP server page.
Setting
Description
TCP/IP port
Enter the TCP/IP port of the receiver.
Allow connections
from
Specify the number of users that are allowed to connect to the data stream via TCP/IP.
• Minimum of 1 user, maximum of 10 users.
• This setting is only available for receivers with the GRL115, Multi-Client and Ntrip
Caster option key loaded. For all other receivers the number of users is fixed to 1.
The option can be purchased from Leica Geosystems.
Limit access range
Select the range of IP addresses, which are authorized to access the receiver.
The valid IP range is from 1.0.0.0 to 223.255.255.255.
Press to go back to the previous wizard step. Press to continue to the next wizard step.
