186
mgmt
--mib-2
--system
--interfaces
--...
--host
--hrSystem
--hrSystemUptime
--...
Each parameter has a unique object ID assigned to it. This can then be used to query the particular parameter.
In order to obtain the object ID (OID) of the particular parameter you want to monitor, you can use "MIB browsers" to manually query
which parameters are supported by a certain network device.
The following table lists some important parameters that could be monitored using SNMP.
Parameter Description
Name
Object ID
System Information
System Contact
sysContact
.1.3.6.1.2.1.1.4.0
System Name
sysName
.1.3.6.1.2.1.1.5.0
System Location
sysLocation
.1.3.6.1.2.1.1.6.0
System Uptime
sysUpTime.0
.1.3.6.1.2.1.1.3.0
Ethernet Interface
Status
ifOperStatus.3
.1.3.6.1.2.1.2.2.1.8.3
Incoming Octets
ifInOctets.3
.1.3.6.1.2.1.2.2.1.10.3
Outgoing Octets
ifOUtOctets.3
.1.3.6.1.2.1.2.2.1.16.3
USB Interface
Status
ifOperStatus.2
.1.3.6.1.2.1.2.2.1.8.2
Incoming Octets
ifInOctets.2
.1.3.6.1.2.1.2.2.1.10.2
Outgoing Octets
ifOUtOctets.2
.1.3.6.1.2.1.2.2.1.16.2
More information on SNMP can be found on the websites mentions below:
Example of a free MIB browser:
http://ireasoning.com/mibbrowser.shtml
Find more information on the management information base and the contained parameters here:
http://www.iana.org/assignments/smi-numbers
This document also lists "requests for comments" (RFC) documents describing the parameters in more detail, e.g
http://www.faqs.org/rfcs/rfc1514.html
General information on SNMP:
http://en.wikipedia.org/wiki/Simple_Network_Management_Protocol
http://en.wikipedia.org/wiki/Management_information_base
Receiver setup: Tools
Receiver Setup: Tools - Overview
The Receiver Setup: Tools page allows:
