Satellite Health
GPS, GLONASS, Galileo, BeiDou and QZSS
Healthy
Lists the PRN numbers of the healthy satellites.
Bad
Lists the PRN numbers of the unhealthy satellites. The satellites are available in the
almanac but are flagged unhealthy.
Not available
Lists the PRN numbers of the unavailable satellites. The satellites are not available in the
almanac.
To enable or disable the automatic update of the status page, please go to Receiver setup: Web server and
activate or deactivate the Automatic status page reload.
If the health status of a satellite is changed by a user and is different to what is sent in the broadcast
ephemeris, this satellite is shown in brackets. Go to GNSS management: Tracking to changes the health
status of a satellite.
Related topics
Tracking: GPS
Tracking: GLONASS
Tracking: GALILEO
Tracking: SBAS
Tracking: BEIDOU
Tracking: QZSS
GNSS management: Tracking
Status tracking: GPS
Field Description
The table below describes the fields in the Status: GPS tab.
The information shown is dependent on the settings configured on the GNSS management: Tracking page and which satellite options
are available on the receiver.
Press the Refresh icon to update the displayed data.
Field
Description
Sat
The Pseudo Random Noise (PRN) number of the satellite.
Elevation
The elevation of the satellite in degrees. An arrow is shown to indicate if the satellite is rising or
setting.
Azimuth
The azimuth of the satellite in degrees.
S/N L1
The signal to noise ratio on L1. The number is shown in brackets if the signal is not currently being
used in the position calculations.
S/N L2P
The signal to noise ratio on L2P. The number is shown in brackets if the signal is not currently being
used in the position calculations.
S/N L2C
The signal to noise ratio on L2C. The number is shown in brackets if the signal is not currently being
used in the position calculations.
S/N L5
The signal to noise ratio on L5. The number is shown in brackets if the signal is not currently being
used in the position calculations.
URA
The User Range Accuracy (URA) as transmitted in the broadcast navigation message. Only
available for GPS satellites.
IODE
The Issue Of Data Ephemeris (IODE) of the currently used broadcast navigation message. Only
available for GPS satellites.
Health
Description
Healthy
Lists the PRN numbers of the healthy satellites.
Bad
Lists the PRN numbers of the unhealthy satellites. The satellites are available in the almanac but are
flagged unhealthy.
