Last sent
The latency of the last outgoing data stream sent in seconds.
Connection: port
The connection type and port over which the data stream is sent out.
LB2
Description
Icon
Data stream is active.
Data stream is inactive.
Data
Shows which data output is active; Meas.Data (measurement data) and Sat.Data (satellite data).
Message
The configured message type (D or E) that is sent.
Data rate
The configured rate at which data is sent out.
Connection: port
The connection type and port used.
NMEA
Description
Icon
Data stream is active.
Data stream is inactive.
Message
The configured NMEA messages activated for the outgoing data stream.
Click the listed NMEA messages to view additional properties.
NMEA message properties
The table below describes the additional NMEA message properties that are shown when the
underlined NMEA Messages are selected.
NMEA
message
properties
Description
Message
The configured NMEA messages activated for the outgoing
data stream.
Rate
The configured data rate for the NMEA message.
Connection: port
The connection type and port over which the data stream is sent out.
BINEX
Description
Icon
Data stream is active.
Data stream is inactive.
Message
The configured BINEX messages activated for the outgoing data stream.
Click the listed BINEX messages to view additional properties.
BINEX message properties
The table below describes the additional BINEX message properties that are shown when the
underlined BINEX Messages are selected.
NMEA
message
properties
Description
Message
The configured BINEX messages activated for the outgoing
data stream.
Rate
The configured data rate for the BINEX message.
Connection: port
The connection type and port over which the data stream is sent out.
To enable or disable the automatic update of the status page, please go to Receiver setup: Web server and
activate or deactivate the Automatic status page reload.
