USB and SD Card Cover: GR25/50
The GR25/50 has a USB port and an SD card slot.
b. SD card slot
c. USB host port
USB client port
The USB port can be used:
• to connect the GR25/50 to a computer and access the Web interface and FTP server.
• connect the GR25/50 to a CS10/ CS15 Field controller and access the Web interface.
USB host port
The USB host port can be used to:
• connect a USB mass storage device to the GR25/50 and push MDB and RINEX data from the SD card.
SD card slot
Data is stored on a removable SD card. For more information on how to work with the SD card, refer to Working with the Memory
Device.
If no SD card is inserted, data storage is not possible.
Unplugging connection cables or removing the SD card during data logging or streaming can cause loss of
data. It is recommended to switch off the instrument before removing the SD card.
While other SD cards can be used, Leica recommends to only use Leica SD cards and is not responsible for
data loss or any other error that can occur while using a non-Leica card.
SD cards can directly be used in the Leica USB Card Reader (767895 MCR7). Other computer card drivers
can require an adaptor.
If formatting the SD card is necessary, we highly recommend to format the SD card on the instrument. Refer
to the How to reset the receiver settings - Step-by-step format the SD card for detailed instructions.
SD card capacity
• Maximum supported capacity: 32 GB.
