Leica GR30 - Status: Sky Plot; Background Information; Status: Data Streams; Status: Data Streams - Outgoing

6: Context sensitive help
69
Tracking: BEIDOU
GNSS management: Tracking
Status: Sky plot
Background Information
The sky plot shows which satellites are currently available and which ones are tracked. Satellites that are available but not tracked, e.g.
due to obstructions, are shown in grey.
Clicking onto a satellite icon or the PRN number will open a text box showing its:
• Azimuth
• Elevation incl. an arrow indicating if satellite is ascending or descending
• SNR values of all available frequencies of this satellite.
Clicking onto the text box another time will make it disappear.
Note:
In order to display the sky plot, the browser must support SVG (Scalable Vector Graphics).
Browser
Version supporting SVG
Internet Explorer
9 and higher
Mozilla Firefox
4 and higher
Opera
11 and higher
Safari
5 and higher
Google Chrome
10 and higher
Status: Data streams
Status: Data streams - Outgoing
Background information
Displays a list of all configured Outgoing data streams from the receiver.
Field Description
The table below describes the fields in the Data streams / Outgoing tab.
The information shown is dependent on the settings configured via the Data stream wizard on the GNSS management: Data streams /
Outgoing tab page
The data streams can be sorted by each field by clicking on the header.
Press the Refresh icon to update the displayed data.
Real time
Description
Icon
Data stream is active.
Data stream is inactive.
Type/Message
The configured message type and version.
Click on the underlined message type to open a list box showing how many satellites are used.
Data rate
The configured rate at which data is sent out.
