Field Descriptions
The table below describes the fields in the Status: Position page.
Press the Refresh icon to update the displayed data.
Position quality (Position type)
Longitude,
Ellipsoidal
height
Shows the currently calculated position of the
receiver in geodetic coordinates.
column shows the
current Position
quality (Navigated,
DGPS or RTK fixed) as
calculated from the
incoming correction
data stream and the
Position type
(Reference station,
Monitoring, Network
RTK) as selected for
the incoming real time
data stream.
Shows the entered reference position of the receiver
in geodetic coordinates.
Shows the currently calculated position of the
receiver in Cartesian coordinates.
Shows the entered reference position of the receiver
in Cartesian coordinates.
The rate at which the position is currently
calculated. Per default 1s. If an incoming real
time data stream or an outgoing NMEA data
stream are configured, the highest configured
data rate is used.
in X
The Displacement in X shows the difference in X between the currently calculated position and the
entered Reference Position
in Y
The Displacement in Y shows the difference in Y between the currently calculated position and the
entered Reference Position
in Z
The Displacement in Z shows the difference in Z between the currently calculated position and the
entered Reference Position.
The current time in the local time system.
Daylight saving time is not accounted for.
latency
The latency of the computed position.
Latency is typically attributed to the time required for data transfer and computation of position.
The Horizontal Dilution of Precision (HDOP) of the current position solution.
The Vertical Dilution of Precision (VDOP) of the current position solution.
The Geometric Dilution of Precision (GDOP) of the current position solution.
The Position Dilution of Precision (PDOP) of the current position solution.
2D coordinate quality of the computed position.
