4: User Interface
25
flashing red
Charging of the internal battery is activated but there is an error in
charging the battery.
Recommended user action: Check and
reattach the battery. If the problem does
not disappear, please send the battery to
Leica Geosystems Service.
Charging is only indicated via LEDs when
the instrument is turned off. When the
instrument is on, the LEDs indicate the
current power level.
Troubleshooting: If the GR25/50 is off and
the user tries to turn on the receiver but the
configured power up voltage is higher than
the current input voltage, the receiver will
not boot. The power LED will flash three
times to indicate the higher power up
voltage.
Please attached a higher voltage power
source.
OR
Press and hold the power button until the
power LED turns green (approximately
30s). This will overwrite the configured
power up voltage.
SD card LED
off
No SD card inserted or power is off.
green
SD card is inserted. The free space on the SD card is greater than
20%.
flashing green
Use of external USB drive is configured but the device is not
available. Data is written to the SD card. The free space on the SD
card is greater than 20%.
yellow
The free space on the SD card is below 20%.
Recommended user action: Activate the
Smart clean-up or the automatic file delete for
each logging session.
flashing yellow
Use of external USB drive is configured but the device is not
available. Data is written to the SD card. The free space on the SD
card is below 20%.
red
SD card is full. Data logging has stopped.
Recommended user action: Immediately
activate the Smart clean-up or the automatic
file delete for each logging session.
Raw data
logging LED
off
No active logging sessions or power is off.
green
Active logging sessions are configured on the instrument and data is
being logged
