LEMKEN Primus 10 - Flush the Pipe System before Interruption

Operation
120
6.17.1 Flush the pipe system before interruption
Description*
* Position designations correspond to the position designations of the fluid lines.
The spray pump (H) draws the water from
the clean water tank via the switching val-
ve (C), the selection valve (A) and the suc-
tion filter (9). The water is then pumped to
the nozzles via the diverting valve (D) and
the pressure filter (3).
H
5
2
G
D
F
C
A
21
3
9
20
