LEMKEN Primus 10 - Spacer; Nozzle Holders; Single Nozzle Holder

Layout and description
61
4.25 Spacer
The spacers ensure the minimum distance
to the ground is maintained when the spra-
yer boom moves vertically.
4.26 Nozzle holders
The unit can be equipped with the follo-
wing nozzle holders:
 Single nozzle holder
 Triple nozzle holder
Nozzles (1) with bayonet caps (2) can be
attached to the nozzle holders.
4.26.1 Single nozzle holder
One nozzle (1) can be attached to each of
the single nozzle holders (3).
1
2
3
