Technical data
180
 The maximum payloads of the device are listed on its type plate.
 If the load capacity of the wheels is lower than the stated axle loads, the per-
missible axle load shall be reduced in accordance with the load capacity of the
wheels, taking into account the permissible maximum speed.
 The permissible gross weight must also be reduced in accordance with the
permissible axle load.
10.2 Drawbar
Maximum permissible (technologi-
cally):
 Support load [kg]:
1142
 Tractor mass [kg]:
13500
 D value [Kn]:
50.30
 Highest speed [km/h]:
40
10.3 Connecting fixture and drawbar extension
The drawbar is installed to be rigid or
spring-loaded. The drawbar has an inter-
face for a drawbar extension.
For the drawbar or the drawbar extension,
the following connecting fixtures are provi-
ded for:
Ring coupling
Traction loops
Ball clutch
50 mm Ø
40 mm Ø
K 80, straight
Ring coupling 50 mm Ø,
cranked
40 mm Ø,
cranked
K 80,
cranked downward
Ring coupling 50 mm Ø,
rotatable
